Configuring the LonWorks Network 4-7
20-COMM-L LonWorks Adapter User Manual
Publication 20COMM-UM008B-EN-P
Variable: nviNV_config
Format: UNVT_DPI_CONFIG
Explanation:
This network variable input provides information on how parameters should
be mapped to network variables. The NVI contains two fields:
• NV_index
• DPI_parameter
To check an already existing configuration, use the following procedures:
A. To check which DPI parameter a network variable is connected to, use
nviNV_config with the following data:
UNVT_DPI_CONF.NV_index = NV_index to check
UNVT_DPI_CONF.DPI_parameter = 65535 (decimal)
B. To check which network variable a DPI parameter is connected to, use
nviNV_config with the following data:
UNVT_DPI_CONF.NV_index = 255 (decimal)
UNVT_DPI_CONF.DPI_parameter = DPI parameter to check
The result of the requests above are placed in nvoFB_config. If there is no
configuration available, 0 (zero) is returned.
Valid Range:
NV_index out: 14…20
NV_index in: 31…36
Module Configuration
LON SNVT NV_Index Default PowerFlex 70/700
Drive Parameter
nvoDrvSpeed 14 1
nvoDrvCurnt 15 3
nvoDrvPwr 17 7
nvoDrvVolt 18 6
nvoDrvRunHours 19 10
nvoDrvFreqAct 20 1
LON SNVT NV_Index Default PowerFlex 70/700
Drive Parameter
nciNmlSpeed 31 44
nciMinSpeed 32 81
nciMaxSpeed 33 55
nciRampUpTm 34 140
nciRampDownTime 35 142
nciNmlFreq 36 43
