1-6 Getting Started
20-COMM-L LonWorks Adapter User Manual
Publication 20COMM-UM008B-EN-P
Quick Start This section is provided to help experienced users quickly start using the
adapter. If you are unsure how to complete a step, see the referenced chapter.
!
ATTENTION: Risk of injury or equipment damage exists.
When a system is configured for the first time, there can be
unintended or incorrect machine motion. Disconnect the motor
from the machine or process during initial system testing.
!
ATTENTION: Risk of injury or equipment damage exists. The
examples in this publication are intended solely for purposes of
example. There are many variables and requirements with any
application. Rockwell Automation does not assume responsibility
or liability (to include intellectual property liability) for actual use
of the examples shown in this publication.
Step Action See
1 Review the safety precautions for the adapter. Throughout This Manual
2 Verify that the PowerFlex drive is properly installed. Drive User Manual
3 Install the adapter.
a. Verify that the PowerFlex drive is not powered.
b. Connect the adapter to the drive using the Internal Interface
cable.
c. Use the captive screws to secure and ground the adapter to
the drive.
d. Connect the adapter to the network using a network cable.
NOTE: When installing the adapter in a PowerFlex 750-Series
drive, see the 20-750-20COMM and 20-750-20COMM-F1
Communication Carrier Cards Installation Instructions,
publication 750COM-IN001, supplied with the card.
PowerFlex 7-Class DPI
Network Communication
Adapter Installation
Instructions, publication
20COMM-IN004) and
Chapter 2 ,
Installing the Adapter
4 Apply power to the adapter.
a. Verify that the adapter is installed correctly.
The adapter receives power from the drive.
b. Apply power to the drive.
The status indicators should be green. If they flash red, there
is a problem. See
Chapter 5 , Troubleshooting .
c. Configure and verify key drive parameters.
Chapter 2 ,
Installing the Adapter
5 Configure the adapter for your application.
Set adapter parameters for the following functions as required by
your application:
• I/O configuration
• Fault action
Chapter 3 ,
Configuring the Adapter
6 Set up the network to communicate with the adapter.
Use a network tool, such as LonMaker, to configure the adapter
on the network.
Chapter 4 ,
Configuring the
LonWorks Network
