Supported Linear Sensors
Important: Only one Linear Sensor can be installed at a time.
Temposonics Linear Sensors
Temposonics® R-Series Linear sensors with MTS® part numbers ending in
1S2G1102 work with the MDI Option.
Temposonics® is a registered trademark of MTS Systems Corporation.
Stahltronic Linear Sensor
Stahltronic WCS Position Encoding System works with the MDI Option.
Supported Rotary Encoders
Please note that encoders must be ordered as "Single Ended". This will
ensure that the RS-485 channel has the proper termination network installed
at the factory.
SINCOS
®
,
SINCODER
®
and
LINCODER
®
are registered trademarks of Stegmann Inc.
Part Number
Character
Characteristic
1
Input Voltage = +24V dc
S
SSI output
2
Data Length = 24 Bits
G
Output Format = Gray Code
1
Resolution = 0.005 mm
1
Performance = Standard
02
Scale Orientation = Forward-acting Synchronized
Characteristic
Input Voltage = +24V dc
SSI output
Data Length = 19 Bits
Output Format = Binary or Gray Code
Resolution = 0.80 mm
Model
Resolution
Comment
SINCOS® SCS-60, SCS-70,
SCM-60, and SCM-70
512 sine cycles per revolution.
SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SCS-KIT-101 and
SCM-KIT-101
1024 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SRS-50, SRS-60,
SRM-50, and SRM-60
1024 sine cycles per revolution. SRM-50 and SRM-60 have built-in
mechanical turns counter.
SINCOS® SRS/M 25
1024 sine cycles per revolution SRS25 and SRM25 have built-in
mechanical turns counter. IP65
Protection Class. Size 25 square
flange mounting.
SINCOS® SRS660
1024 sine cycles per revolution Hollow-shaft up to 14 mm diameter
SINCOS® SHS-170
512 sine cycles per revolution. While the software supports this
encoder, the SHS-170 draws
excessive current and should only be
used with an external power supply.
