Step 10: Document the
Change
Document the installation of the MDI option board on the Field Installed
Options label. Use the blank line if you are installing the MDI option board
in a drive that was manufactured without it.
Frame 1 - 6 Size Drives
Frame 9 - 13 Size Drives
FIELD INSTALLED OPTIONS
Firmware
#:
Date
Firmware
20-HIM
28-IO-
20-COMM-
20B_-DB1-
HIM
I/O
COM Module
Internal Dynamic Brake
#:
Date
TIP: Use packing material from new MDI option board to return the
replaced MDI option board
