DVRI Installation
Installation Manual
DV 5-9-13
Commissioning (Balancing)
Uninstall the front cover for maintenance. For Size < 10 the
balancing port is positioned on the side of the unit behind
the white plug and For Size > 12 the balancing port is
positioned in the center behind the decor strip. The K-factor
of the unit is stated on K-factor label mounted on long
bracket behind the front cover for Size < 10 and on one of
the side of the balancing port for Size > 12. The k-factor
can also be found on our website in the relevant k-factor
guide. See Figure 4
6.2
FIGURE 4
