Skyjacker SKTOY30 - Manual (Page 2)

Pg 2
7. Disconnect sway bar end link and upper ball joint. This will
allow the steering knuckle to drop allowing for an easier
installation. Attach the upper bracket to factory tower using
"3" 7/16" x 1 ½" fine thread bolts and self-locking nuts.
Bolts come from bottom of bracket through the top.(See
Photo #3).
8. Using a pry bar, pry the lower A-Arm down to allow for
installation of the lower shock bolt. Install so that thickest
bushing is toward the C.V. Shaft. (See Photo #4). Install
using factory bolt.
9. With Coil Over installed, Place a bottle jack under the lower
A-Arm. Raise the lower A-Arm and re-attach upper ball
joint. Re-attach sway bar end links.
10. Be sure to lock the upper spanner using the provided
spanner wrench. (See Photo #6 and #7)
11. Lower the vehicle to the ground and measure the amount
of lift gained. Due to different engines and aftermarket
accessories such as winches and bumpers, the ride height
may need to be adjusted.
12. If the height is too high or too low, raise the vehicle again
from the cross member to relieve the load on the coil.
Using the supplied spanner wrench, adjust the upper
spanner up or down as needed. Lower vehicle back on
the ground and re-measure ride height. Repeat this
process as necessary.
Photo #3
Photo #4
Photo #5
Photo #7 Photo #6
