87
Key
No.
Description
[Quantity] Part Number
SCG-3 SCG-4 SCG-5 SCG-6 SCG-7 SCG-8 SCG-9
5. BURNER ASSEMBlIES
5A
Gas Valve (Natural Gas),
Honeywell VR8204P1171
81660282 N/A
Gas Valve (Natural Gas),
Honeywell VR8304P4496
N/A 81660283
Gas Valve (LP Gas),
Honeywell VR8204C3015
81660146 N/A
Gas Valve (LP Gas),
Honeywell VR8304P4280
N/A 81660160
5B
Nipple, ½” NPT x Close 806600040 N/A
Nipple, ¾” NPT x Close N/A 806600022
5C
Union, ½” NPT 806604023 N/A
Union, ¾” NPT N/A 806604001
5D
½” Gas Manifold 82207031 82207041 82207051 82207061 --- --- ---
¾” Gas Manifold --- --- --- --- 82207071 82207081 82207191
5E
Burner Orifices - Natural Gas #47
(4)
822710
(6)
822710
(8)
822710
(10)
822710
(12)
822710
(14)
822710
(16)
822710
Burner Orifices - LP Gas 1.20 mm
(4)
822792
(6)
822792
(8)
822792
(10)
822792
(12)
822792
(14)
822792
(16)
822792
5F
Pilot Assembly - Natural Gas 8236163
Pilot Assembly - LP Gas 8236164
5G Pilot Burner 100147-01
5H Main Burner
(3)
100146-01
(5)
100146-01
(7)
100146-01
(9)
100146-01
(11)
100146-01
(13)
100146-01
(15)
100146-01
5J Pilot Tubing 8236122
5K Self Tapping Screw, ¼ - 20 x ½” (6) 80860700
