PULL TYPE WINDROWER
PRE-DELIVERY CHECKLIST
Windrower Model: Serial No:
Perform these checks and adjustments prior to delivery to your customer. See the Operator's Manual and
Assembly Instructions for adjustment details.
CAUTION: Carefully follow the instructions given. Be alert for safety related messages
which bring your attention to hazards and unsafe practices.
‰ Check for shipping damage or missing parts.
‰ Bleed right reel lift cylinder.
‰ Center reel between end sheets.
‰ Adjust reel fore-aft position.
‰ Check reel drive idler arm is properly located for reel fore-aft position.
‰ Adjust reel clearance from cutterbar. (2 in. [50 mm])
‰ Check main drive belt idler alignment.
‰ Check main drive idlers mounting bolt torque. (80 - 90 ft. lbs. [110 - 120 N ⋅m])
‰ Grease float adjusting screw.
‰ Check header flotation (100 - 150 lbs. [450 - 650 N])
‰ Grease all bearings.
‰ Grease both wheel casters until grease is forced out top or bottom of caster bearing.
‰ Check tire pressure – 24 to 28 psi (165 – 190 kPa).
‰ Turn drives by hand to check for binding. AVOID PINCH POINTS.
‰ Check draper tracking and tension.
‰ Adjust cutterbar level.
‰ Run machine for 15 minutes, STOP MACHINE and check drives for belt/idler alignment and heated
bearings. Check knife sections for discolouration caused by misalignment of components.
‰ Check hydraulic hose routing, ensuring adequate clearance with header and reel up or down.
‰ Convert machine to transport position:
‰ Check telescoping hitch operation.
‰ Check transport pins install easily.
‰ Check wheels caster properly into position.
‰ Check transport width.
‰ Bleed right wheel lift cylinder.
‰ Check routing of electrical wiring and hoses in transport.
‰ Check lights are functional.
Date Checked: Checked By:
