MAINTENANCE/SERVICE
GREASING THE WINDROWER
100 Hours or Annually (continued):
8. Draper Drive Roller Bearings (H) - two fittings
9. Reel Drive Pulley Hub (K) - one fitting
11. Wheel Hub Bearings (M) – two fittings
10. Split Reel Connector Block (L)
36’ – one fitting
DRAPER DRIVE ROLLER BEARINGS
H
REEL DRIVE PULLEY HUB
K
SPLIT REEL CONNECTOR BLOCK
36’ ONLY (not exactly as shown)
L
WHEEL HUB BEARINGS
M
