Maintenance/service – MacDon 3020 Pull-Type Windrower User Manual
Page 49
38
MAINTENANCE/SERVICE
GREASING THE WINDROWER (continued)
50 Hours:
1. Main Hitch Pivots (A) - four fittings
2. Wheel Casters (B) & (C) - two fittings
3. Reel Support Bushings (D)
21, 25, 30 ft. - two fittings
36 ft. - three fittings
MAIN HITCH PIVOTS
A
LEFT WHEEL CASTER RIGHT WHEEL CASTER
B
C
REEL SUPPORT BUSHINGS
D
