MAINTENANCE AND SERVICING
169454
69
Revision C
7.4.1 Maintenance Schedule/Record
ACTION:  - Check  - Lubricate  - Change
MAINTENANC
E
RECORD
Hour Meter Reading
Date
Serviced By
FIRST USE Refer To Section 7.4.2 Break-in Inspections
100 HOURS OR ANNUALLY* Also See Section 7.4.3 Pre-Season / Annual Service
 Hydraulic Oil Filter
First 100 H Only - Section 7.7.2

Wheel Bolt Torque - Section 7.9.1

Wheel Hub Bearings - Section 7.4.5

Conditioner Drive Belt - Section 7.6.5

Bevel Gearbox Lube Level - Section 7.4.5
END OF SEASON Refer To Section 7.4.4 End of Season Service
10 HOURS OR DAILY
NOTE: A RECORD OF DAILY MAINTENANCE IS NOT
NORMALLY REQUIRED, BUT IS AT THE
OWNER/OPERATOR’S DISCRETION.

Hydraulic Hoses and Lines
 Cutter Blades, Deflectors and Discs
- Section 7.5

Tire Pressure - Section 7.9.3

Hydraulic Oil Level - Section 7.7.1
25 HOURS

Roll Universal Shafts - Section 7.4.5

Cutterbar Driveline Universals - Section 7.4.5

PTO Shaft and Universals - Section 7.4.5
50 HOURS
 Cutterbar Lube
First 50 and 150 hours - Section 7.5.1
 Bevel Gearbox Lube
First 50 and 150 hours - Section 7.6.7.1

Drive Belt Tensioner - Section 7.4.5

Roll Shaft Bearings - Section 7.4.5

Lower Link Pivots - Section 7.4.5

Lift Cylinder Pivots - Section 7.4.5

APT Swivel - Section 7.4.5

Steering Cylinder Pivot - Section 7.4.5

APT Pivot - Section 7.4.5
