Page 23

6.0
SPECIFICATIONS
Description
iConverter
1-Module Redundant-Power Chassis
Ports
2 x RJ-45
Protocols
10Base-T, 100Base-Tx with 1536 max. frame size
Cable Types
UTP
EIA/TIA 568A/568B
Connector Types
UTP
RJ-45
Contact Closure Sensors
Field-wireable 16-24 AWG
Power Requirements
Low Voltage DC Power
9 - 24 VDC
1.5A @ 9.0VDC
Low Voltage DC Power
Connector
2.5mm Barrel Connector or Field-wireable 16-20 AWG Terminal Connector
High Voltage DC Power
+24 to +60 VDC
or
-24 to -60 VDC
0.3A @ 48VDC
High Voltage DC Power
Connector
Field-wireable 16-20 AWG Terminal Connector
PoE Power
+44 to +57 VDC
or
-44 to -57 VDC
0.27A @ 48VDC
PoE Connector
RJ-45 IEEE 802.3af-2003 Alternative A & B,
Pre-standard Cisco PoE
AC Power Adapter [US]
100-120 VAC, 60Hz
0.2A @ 120VAC
AC Power Adapter [Universal]
100-240 VAC, 50-60 Hz
0.2A @ 120VAC
Dimensions
5.4" (W) x 6.8" (L) x 1.0" (H)
Weight
without power adapter
1.5 lbs.
with power adapter
2.0 lbs.
Compliance
UL, CE, FCC, AS/NZS 3548, & VCCI Class A
Temperature
Operational - Commercial
0 to +50
o
C
Operational - Wide Range
-40 to +60
o
C
Storage
-40 to +80
o
C
Humidity (non-condensing)
5 to 95%
Altitude
-100m to 4000m
MTBF [hrs]
without power adapter
540,000
with US power adapter
250,000
with Univ. power adapter
100,000
Table 7: Model Specifications
Refer to Table 1 for applicable product features.
