4.2
MODULE MANAGEMENT MODE
From the Module configuration screen, the management mode can be changed. Select option 18 to change
the mode. The management mode options will be displayed.
PI
Module - iConverter GX/TM iConverter, Serial Agent
Identifier -
Chassis Number =
1
Switch ON Condition
OFF Condition
H/W
Actual
Slot Number =
2
1: Fiber Manual
Fiber AN
Off
Off
Model Number =
8923-1
2: UTP Manual
UTP Auto-Neg
Off
Off
3: UTP 10/100
UTP 1000
Off
Off
Serial Number =
xxxxxxxx
4: UTP 10 Mbps
UTP 100 Mbps
Off
Off
Manufacturing Date = xxxxxxxx
5: UTP HDX
UTP FDX
Off
Off
Hardware Revision = xx
6: Link Propagate
Link Segment
Off
Off
Software Revision = xx
7: Remote Fault
Normal
Off
Off
8: Symm Fault Det
Normal
Off
Off
LED
9: BP A Enabled
BP A Disabled
Off
Off
1: Power =
On
10: BP B Enabled
BP B Disabled
Off
Off
2: Power Supply 1 =
Off
11: Pause Enabled
Pause Disabled Off
Off
3: Power Supply 2 =
On
12: Slave Only
Master/Slave
Off
Off
4: Power Supply 3 =
Off
13: UTP Manual-X
UTP Auto-X
Off
Off
5: Fiber Link =
Off
14: UTP Crossover
UTP Through
Off
Off
6: BP Master =
Off
15: Not Available
7: UTP 100+10 Link = Off
16: Not Available
8: UTP 1000+10 Link= Off
OAM settings:
9: UTP FDX =
Off
17: IP Protocol State Off
18: Management Mode Auto ah
Toggle Switch(1-16), (I)dentifier, (R)eset, (H)elp, (P)ortStat, Port(C)tl >
Mode (1=OAM Off, 2=Auto Secure OAM, 3=Auto ah OAM, 4=Secure OAM, 5=ah OAM): 3
The GX/TM module supports several management options. Option 18 configures how the module will
communicate to its remote partner. ‘Auto Secure OAM’ (option 2) and ‘Secure OAM’ (option 4) uses
Omnitron’s proprietary secure encrypted management channel. ‘Auto Secure OAM’ will force the remote
partner to communicate using the Secure OAM protocol while ‘Secure OAM’ will only attempt to
communicate with the remote partner over the secure protocol. The management channel can support IP or
IP-less connectivity based on the configuration of the ‘IP Protocol State’, option 17. ‘Auto ah OAM’
(option 3) and ‘ah OAM’ (option 5)’ conforms to the IEEE 802.3ah specification. ‘Auto ah OAM’ will
force the remote partner to communicate using the ah OAM protocol while ‘ah OAM’ will only attempt to
communicate with the remote partner over the ah protocol. This option provides an industry standard
method of fault detection and monitoring. The management channel supports both IP and IP-less connectivity
based on the configuration, option 17 and 18.
NOTE: See NetOutlook User Manual for complete information on the management modes.
