Set Initial Limit and Error Detectors
You can reduce the chances of equipment damage or injury by setting limit and error detectors.
Warning
:
Setting limits and error detectors can help reduce the chance of equipment damage or injury.
Unexpected actuator movement can cause equipment damage or injury.
Do not rely entirely on limit or error detectors when gaining control of the actuator. Always
make sure the actuator cannot contact anything if it were to go to full travel in either direction
when you are gaining control of the actuator.
1. Set narrow displacement limits to minimize any unexpected actuator movement when you first take
control.
MTS TestLine Test System Operation | 57
Running the Example HCF Test
