SWIFT 10 ATV Sensors 88
Road Simulator
Installing the Transducer
Attaching SWIFT Components to the Fixturing
Material required:
• Molykote g-n paste (MTS part number 011-010-217).
• Nikal based anti-galling compound (MTS part number 011-354-902)
1. Clean all surfaces with a mild detergent, such as dish soap. It is critical that
all surfaces be free of stones, burrs, and grease. Use an alcohol-based
solvent to remove grease.
Important It is imperative that the mounting surfaces of the transducer be
protected from getting scratched. Any wheel components and work
surfaces that might come in contact with the transducer must be
clean, smooth, and free of debris
2. Wipe the unpainted mating surfaces of the inner hub adapter, the transducer,
the slip ring bracket assembly and the washer plate with a clean dry cloth.
Use cottons swabs or other soft tool to clean the coupling teeth on the inner
hub adapter, transducer, and the slip ring bracket.
3. Attach the inner hub adapter to the vehicle spindle. Torque the lug nuts in a
cross-pattern to the torque rating recommended by the wheel manufacturer.
SWIFT 10 Fasteners
Q UANTITY F RONT AND R EAR
16 M10 X 1.50 X 30 mm long
20
M8 X 1.25 mm *
* The length of these fasteners is dependant on the thickness of the
rim flange and washer plate. The fastener length must ensure a
minimum thread engagement of 12 mm (0.47 in) into the rim flange
but must not protrude through the rim where it could interfere with
vehicle brake calipers, uprights, rotors, etc.
8
M8 X 1.25 mm †
† The length of these fasteners is dependant on the design of the
inner hub adapter. The fastener length must ensure a minimum
thread engagement of 12 mm (0.47 in) but must not extend through
the inner hub adapter such that it would interfere with or contact the
spindle face.
Lug nuts and washers ‡
‡ Lug nuts and washers will vary with vehicle and spindle
configuration.
