Cable drawings – MTS SWIFT 10 ATV Sensor User Manual
Page 130
SWIFT 10 ATV Sensors
130
Cable Drawings
Assembly Drawings
Cable Drawings
Cable Drawings
P
ART
N
UMBER
C
ABLE
D
ESCRIPTION
572029-XX
Cable Assy - SWIFT Mini Transducer Interface
572129-XX
Cable Assy - SWIFT Mini TI, Power w/PT
572143-XX
Cable Assy - SWIFT Mini TI Power w/lug
100-179-353
Cable Assy - SWIFT mini TI, Monitor
