MTS SWIFT 10 ATV Sensor - Manual (Page 26)

SWIFT 10 ATV Sensors 26
Specifications
Hardware Overview
Specifications
SWIFT 10 ATV Transducer Performance (part 1 of 2)
P ARAMETER S PECIFICATION
Use
SWIFT 10 ATV (aluminum) for:
SWIFT 10 ATV (titanium) for: low weight, high sensitivity, lower measured forces
high fatigue life, longer durability, higher loads
Maximum usable rpm 2,200
Maximum speed 250 kph (155 mph)
Shock resistance, each axis 150 G
Fits rim size (usable range)
7-12 inch
*
Number of Lug nuts accommodated 4
Hub bolt circle diameter accommodate All
Wheel stud size accommodated All
Input voltage required 9–30 V DC
Input power required per transducer 7 Watts maximum (22 Watts typical)
Output voltage ± full scale calibrated load
±10 V †
SAE J328
Rated load capacity ‡
Bending moment §
Aluminum
2.5 kN (550 lbf)
1.45 kN•m (12 869 lbf•in)
Titanium
4.2 kN (925 lbf)
4.76 kN•m (42117 lbf•in)
Full scale calibrated ranges Consult the calibration range sheet that accompanies each
transducer
Resolution Infinite
Performance accuracy
Nonlinearity
Hysteresis
Modulation
Cross talk #
1.0% full scale
0.50% full scale
≤5.0% reading
1.5% full scale
Maximum operating temperature ** 125°C (257°F
Assembly Weight – single wheel
Transducer
Aluminum hub adapter/spacer
Slip ring assembly
Modified aluminum rim
Lug nuts
Outer steel washer plate
Attached fasteners
Total 1.4 kg (3.0 lb)
0.5 kg (1.0 lb)
0.5 kg (1.1 lb)
2.4 kg (5.3 lb)
0.1 kg (0.2 lb)
0.2 kg (0.4 lb)
0.8 kg (1.8 lb)
5.8 kg (12.8 lb)
2.0 kg (4.5 lb)
0.5 kg (1.0 lb)
0.5 kg (1.1 lb)
2.4 kg (5.3 lb)
0.1 kg (0.2 lb)
0.2 kg (0.4 lb)
0.8 kg (1.8 lb)
6.5 kg (14.3 lb)
