SWIFT 10 ATV Sensors
114
Maintenance
Transducer Interface
The electronics for your transducer have no internal parts that can be serviced by
the user. The case is sealed against moisture. Breaking the seal by opening the
case can void any warranty.
As required
Before making any cable connections to the TI box, inspect the area of the
connector for accumulated dirt.
If necessary, clean the connector areas with low pressure air or an electrical
connector cleaner.
