SWIFT 10 ATV Sensors 86
Road Simulator
Installing the Transducer
Do not use high-pressure air to clean debris from around the transducer
connectors.
High-pressure air can damage the silastic seals and may void the warranty.
Use a brush with fine, non-metal bristles and low air-pressure [0.07 MPa (10 psi)]
to clean debris from around the transducer connectors.
Do not under-torque the lug nuts.
Lug nuts that are not properly tightened can become loose during testing.
Loss of a wheel can cause damage to the test vehicle and transducer and
result in serious injury, death, or property damage.
Always tighten the lug nuts to the torque rating recommended for the vehicle/
wheel. Recheck the torque daily and/or before each testing session.
Equipment required This procedure requires one person. To install the transducer, you will need the
following equipment:
• Spindle adapter spacers (see next figure)
• Adapters to 329 simulator
• Anti-rotate assembly (including customer-supplied mounting arm)
• Small set of metric hex-head wrenches
• Tube bender for the restraint tube
• Tube cutter
• Metric socket head drive set (up to 14 mm) with extension
• Molykote g-n paste, 2.8 oz. tube (MTS part number 011-010-217)
• Nikal based anti-galling compound (MTS part number 011-354-902)
• Transducer mounting bolts (per transducer) 1
20 size M8 X 1.25 mm X 50 mm long
8 size M8 X 1.25 mm X 75 mm long
8 washers 17 mm O.D. X 8.4 mm I.D.
lug nuts and shim washers
CAUTION
WARNING
1. Lengths shown are for reference only. Verify lengths for you specific rim
and hub design.
