MK Diamond Scarifier - Manual (Page 59)

59
iTeM DeScriPTiON ParT# QTY.
1 NUT, HEX, 3/8 - 16 101188 2
2 WHEEL, FRONT 5” x 2” W 138537 2
3 SCREW, 3/8 - 16 X 1 - 1/4 HEX HEAD CAP 150774 2
4 KEY, 1/4 SQR X 1 - 3/4 150796 1
5 WASHER, FLAT, SAE, 3/8 150923 12
6 WASHER, 1/2 SAE FLAT 150924 4
7 WASHER, LOCK, SPLIT, 3/8 150925 10
8 WASHER, FLAT, SAE, 1/4 151915 8
9 NUT, HEX, NYLK, 3/8 - 16 152505 1
10 SCREW, HEX HD, CAP, 3/8 - 16 X 2 153485 1
11 SHIM, .045 THK .750 ID 1.250 OD 153699 6
12 SCREW, SET, SOC, CUP, 3/8 - 16 X 1/2 153710 2
13 COLLAR, SET, 3/4” 153814 2
14 FITTING, 1/4 - 28 GREASE 153852 2
15 PIN, COTTER 18 X 1 - 1/2 153861 2
16 NUT, HEX, TW, 1/4 - 20 153941 8
17 NUT, 1/2 -13 HEX 153943 2
18 LINKAGE, DEPTH FEED 1600/9000 155049 1
19 SCREW, PAN HD, CAP, 1/4 - 20 X 1/2 155452 4
20 SCREW, FLAT HEAD, 1/4 - 20 X /12 PHIL 155812 4
21 SCREW, HEX HD, TAP, 1/2 - 13 X 4 156626 2
22 SCREW, HEX HD, 3/8 - 24 X 1 157803 8
23 WELDMENT, MAIN FRAME 158098 1
24 WELDMENT, TRUCK, SCARIFIER 158099 1
25 SHAFT, DRUM HEX, SCARIFIER 158465 1
26 SHAFT, PULLEY 158466 1
27 HOUSING, BEARING 158467 2
28 BEARING, 207 SERIES 158468 1
29 PULLEY, 16J40 X 1 -1/4 BORE 158472 1
30 SCREW, SOC, HD, CAP, 3/8 - 24 X 3/4 158496 4
31 WHEEL, 4” DIA X 2” W, 3/4 ID BEARING 158520 2
32 AXLE, FRONT 158522 1
33 NUT, HEX JAM 5/8 - 11 UNC LH 158577 2
34 GUARD, SHAFT (COMP) 158581 1
35 ASSY, DUST SCREEN, RIGHT SIDE 158594 1
36 ASSY, DUST SCREEN, LEFT SIDE 158595 1
37 SCREEN, FRONT/BACK, DUST 158596 2
38 BEARING, 1” ID - UCS207 - 1” HEX 160834 1
MK Sg-ii LeSS eNgiNe ParT # 170578
MK-Scarifier ParTS LiST
