MK Diamond Scarifier - Manual (Page 29)

29
MK-Scarifier SeTUP
The Scarifier is capable of performing several different operations simply by changing drum configura-
tion. The following steps describe how it is operated in any configuration.
(A)
Start the Scarifier in accor-
dance with Engine Start, Step
1 of the STARTUP section,
page 24.
(B)
Raise the Cutting Drum to the
highest position.
(C)
Place the Engage/Disengage
Lever in the “Lower” position.
(D)
Adjust the height of the Cut-
ting Drum for the Job being
performed (See Basic Grind-
ing Techniques).
(E)
Locate the Vibration Lock.
(F)
Lock the height of the drum
using the Vibration Lock.
(G)
Adjust the speed
by using the Throttle,
as desired.
(H)
Push the Scarifier at a
smooth, even pace to per-
form the cut.
(I)
Place the Engage/Disengage
Lever in the “Lift” when the
cut is complete.
When turning the Scarifier, lift the Rear Wheels off the ground, and pivot the it on the Front Wheels.
STarTUP
NOTE:
