Mk-scarifier parts list – MK Diamond Scarifier User Manual
Page 55
55
iTeM
DeScriPTiON
ParT#
QTY.
Q
aSSeMBLY, SHafT gUarD
N/a
-
Q1
QA1
GUARD, SHAFT (MK RED)
GUARD, SHAFT (ORANGE)
158581
158581-OR
1
1
Q2
SCREW, 3/8-16 X 1 1/4 HEX HEAD CAP
150774
2
Q3
WASHER, 3/8 SAE FLAT
150923
4
Q4
WASHER, 3/8 SPLIT LOCK
150925
2
Q5
NUT, 3/8-16 HEX
101188
2
r
aSSeMBLY, DrUM BeariNg
N/a
-
R1
HOUSING, BEARING
158467
2
R2
BEARING
158468
1
R3
BEARING, 1” HEX ID
160834
1
R4
SHAFT, PULLEY
158466
1
R5
SCREW, 3/8-24 X 3/4 SOC HEAD CAP
158496
4
R6
PULLEY, 4.0”OD, POLY-V (16J40 X 1 ¼ BORE)
158472
1
R7
SCREW, 3/8-24 X 1 HEX HEAD CAP
157803
8
R8
WASHER, 3/8 SAE FLAT
150923
8
R9
WASHER, 3/8 SPLIT LOCK
150925
8
S
aSSeMBLY, 8” DrUM
158460
1
S1
DRUM, WELDMENT, 8”
158461
1
S2
BUSHING, DRUM (.515 ID) OR (33/64 ID)
158462
18
S3
SHAFT, 8” HARDEN STEEL
158463
6
S4
RING, DRUM RETAINING
158464
2
S5
SCREW, 5/16-18 X ¾ TAP,
151369
6
S6
WASHER, 5/16 SPLIT LOCK
151747
6
S7
WASHER, 5/16 FLAT SAE
151754
6
S8
BUSHING, FLANGED (.515 ID) OR (33/64 ID)
165248
12
T
aSSeMBLY, 8” DrUM, DriVe SHafT
N/a
-
T1
SHAFT, 8” DRUM, DRIVE
158465
1
T2
NUT, 5/8-11 HEX JAM (LEFT HAND THREAD)
158577
2
U
aSSeMBLY, HaNDLeBar
N/a
-
U1
HANDLEBAR
158359
1
U2
HANDGRIP
150842
2
U3
SCREW, 3/8-16 X 1 HEX HEAD CAP
156602
2
U4
WASHER, 3/8 SPLIT LOCK
150925
4
U5
WASHER, 3/8 SAE FLAT
150923
4
MK-Scarifier ParTS LiST
