MK-Scarifier PrODUcT SPecificaTiONS
SPecific WarNiNgS
PrODUcT SPecificaTiON
general Description
Motor and Weight Specifications
Scarifier Usage
features
• Read Owners Manual
• Wear Protective Gear for Head, Lungs, Ears and Eyes
• Engage/Disengage Lever allowing the operator to raise or lower the cutting drum without
changing the cutting depth setting.
• Ergonomically designed handlebar to reduce fatigue.
• Poly micro V-belt to ensure maximum power transfer from the engine to the cutting drum.
Operated and used according to this manual, the Scarifier will provide years of dependable service.
The Scarifiers are is engineered with an 8” Cutting Drum. The SG-9 has a Honda engine and the
SG-5 has a Baldor motor. The scarifier is designed with fine depth control allowing the operator to
make depth adjustments in 1/16-inch increments.
The Scarifiers use a 6-inch diameter, 8-inch long cutting drum with 6 hardened steel shafts that will
accommodate the most common cutting discs.
The Scarifier is designed to grind surfaces, remove old coatings, prepare surfaces before applying
new coatings, roughen surfaces, groove surfaces and slot surfaces.
Depending on cutting wheel style, production rate varies from 350 to 500 square feet per hour for a 1/8-inch
removal depth.
Model MK-Sg-9 MK-Sg-5
Engine/Motor Honda (Gas) Baldor (Electric)
Power GX270 Cyclone 5 HP 230V
Weight (not including drum) 170 lbs. (77kg) 170 lbs. (77kg)
Drum Dimensions (Dia. x L) 6” x 8” 6” x 8”
Drum Weight 30 lbs. (14 kg) 30 lbs. (14kg)
L x W x H (in) 23” x 20” x 43” 23” x 20” x 43”
L x W x H (mm) 813 x 508 x 1,092 813 x 508 x 1,092
Drum Configurations Part # Part #
Scarifier with 5 Point Carbide Drum (no cutters) 158532 158533
Scarifier with 5 Point Carbide Drum 158941 165276
Scarifier with 6 Point Carbide Drum 158942 165277
Scarifier with 18 Point Carbide Drum 158943 165278
Scarifier with 12 Point Carbide Drum 158944 165279
