MK Diamond MK-101Pro24 JCS User Manual
Page 47
47
Item
Description
Part#
Qty
1
WASHER, FLAT, SAE, 3/8
150923
8
2
WASHER, FLAT, SAE, 5/16
151754
10
3
NUT, 3/8 16 NYLOK HEx
152505
4
4
SCREW, 5/16 - 18 x 1 HEx HEAD MACHINE
152520
2
5
NUT, HEx, 8 -32
153549
2
6
SCREW, 5/16 -1 8 x 2 HEx HEAD
155494
2
7
WHEEL, REAR 8"
155986
2
8
NUT, HEx, NYLK, 5/16 - 18
158289
5
9
SCREW, HEx HD, 3/8 - 18 x 4 - 1/4
158604
2
10
RIVET, DOME, 5/32 x .338
158805
4
11
KNOB, RUBBER, 1/4 - 20 x 3/4" LONG BLUE
159428-1B
1
12
KNOB, RUBBER, 1/4 - 20 x 3/4" LONG
159428-1G
1
13
STOP, RUBBLE BUMPER
159855
2
14
NUT, HEx, HYL, 1/4 -20
159857
4
15
WELDMENT, REAR SUPPORT
160693
1
16
PLATE, SPRING
160694
2
17
FITTING, SPRING, GAS, 1 - 1/4"
160695
4
18
SPRING, GAS, 600N STABILOUS
160696
2
19
SPRING, 1/2 x .040 x 1.75"
160697
2
20
WELDMENT, FRONT SUPPORT
160700
1
21
SCREW, SHOULDER, 5/16 x 3/4
160726
4
22
PLUG, PLASTIC, 1 SQ - 14-20 GA
160727-1
2
23
PLUG, PLASTIC, 1 SQ - 10-14 GA
160727-2
6
24
SPACER, 3/4 x 3/8 x 2 - 1/2
160728
2
25
RIVET, CLOSE END, 3/16, DOME STYLE
160729-3
2
26
SPACER, 1/2 x 5/16 x 1 - 1/8
160732
2
27
CASTER, SWIVEL, 3 - 3/8 - 16 STEM
160735
2
28
WELDMENT, VERTICAL SUPPORT
160934
1
29
PIN, LOCKING
160936
1
30
RING, RETAINING, .375 x .035
161171
3
31
PIN, LOCKING (WHEEL)
162051
1
32
SPRING, .600x .045 x 2.25
162052
1
33
RING, RETAINING, .500x .042
162053
1
34
PIN, LOCKING (FRAME)
162055
1
35
CAP, VINYL, 1/2" - 9/16 x .75
162057
3
36
LATCH, FRONT SAFETY
162540
1
37
SCREW, SHOULDER, 5/16 x 2
162555
1
38
SCREW, BTTN, ALN, CAP, #8 - 032 x 3/4
162557
2
39
SPRING, ExTENSION, .25 x .94 x .02
162558
1
40
WELDMENT, FRAME
168827
1
MK-101 PRO24 JCS PARTS LIST
