MK-101 Pro24 JCS PARTS LIST
Item
Description
Part#
Qty
1
FITTING, PLASTIC, 1/4 FNPT x 1/4 BARB
128397
1
2
HOSE, VINYL, 1/4 x 3/8 TSAW
132951
1
3
CASTING, ACC DUAL FLAT-COMP
134577
1
4
WRENCH, TILESAW, 15/16 CSD END
134684
1
5
WASHER, FLAT, SAE, 3/8
150923
3
6
WASHER, LOCK, SPLIT, 3/8
150925
3
7
PUMP, WATER 115V/60Hz UL/CSA
151271
1
8
SCREW, WING, 1/4 - 20 x 1/2
151888
3
9
NUT, HEx, 1/4 - 20
151893
2
10
WASHER, 1/4 SAE FLAT
151915
1
11
WASHER, 1/4 SPLIT COCK
152591
2
12
CASTING, ACC BULLNOSE LRG - COMP
153201
1
13
PAN, WATER
153262
1
14
PLUG, RBBR DRAIN W/O HOLE
153439
1
15
SCREW, SET, SOC, CUPT, 3/8 - 16 x 1/2
153710
1
16
CLAMP, HOSE 1/2 - 3/4
154394
1
17
SHAFT, 12.88 PIVOT
155530
1
18
PLATE, PRESSURE
155671
1
19
SCREW, 3/8 - 16 x 1/2 HEx HEAD CAP
156030
2
20
KNOB, TRI PLASTIC MK-660 1 - 1/2
156770-02
1
21
SCREW, HEx HD 1/4_20 x 1-1/4
157145
1
22
TAG, SERIAL NUMBER, BLANK
157500-RW
1
23
STOP, CUTTING HEAD
157728
1
24
DRIVE SCREW, #7 x 5/16 ROUND HEAD
157849
2
25
CASTING, POST, PRO24 OFFSET-COMP
158405
1
26
ASSY, DC CUTTING HD, MK-101PRO
158481
1
27
KNOB, RUBBER, 1/4 - 20 x 3/4" LONG
159428-1
4
28
PROTRACTOR, 90 DEG
159429
1
29
RIP GUIDE, LARGE DIE CAST (COMP)
159751-RW
1
30
GUARD, SPLASH
160310
1
31
MK-225 10 x 050 x 5/8 4 MM SAWS
160593
1
32
SPACER, 5/8 x .385 x 1.4
160654
2
33
CLAMP, PUMP HOLDING
162054
1
34
ASSY, PORTABLE STAND, JCS
169218
1
35
ASSY, TABLE, PRO-24 JCS
169220
1
