13
PRODUCT SPECIFICATIONS
Motor Baldor (Electric)
Power 1-1/2 HP, 120V
AMP 14.3
Blade RPM 3450
Blade Capacity 10” (254 mm)
Arbor 5/8"
Depth of Cut 3” (76 mm)
Length of Cut 24" (610 mm)
Diagonally Cut 18" (457 mm)
L x W x H (inches) 48" x 24" x 29"
L x W x H (mm)
1,219 x 610 x 737
Weight 156 lbs. (71 kg)
Part # 153243-JCS
Motor available in other electrical configurations.
• Integrated stand allows operator to set up or transport in a matter of seconds
• Solid rubber heavy-duty wheels won't scuff floors
• Designed for easy transport, loading and storage by one person
• Integrated gas shocks help handle the weight of the saw during setup and breakdown
• Wheel latches prevents stand from moving during operation
• Fully enclosed high torque, fan-cooled motor
• Permanently lubricated, dual-sealed, heavy-duty blade shaft bearings
• Multi-position motor post and cutting head for convenient cutting of various tile sizes
• Built-in water distribution system supplies water to both sides of blade
• Variable height cutting head allows for plunge cuts and use of blades smaller than 10" in diameter
• Accommodates 6" and 8" profile wheels
• Micro V-belt drive
• Blade shaft lock for easy blade removal
• Linear-bearing and chrome plated guide-bar assembly ensure precise cutting
• Cast aluminum blade guard and motor post
• Made in the USA
• One-year limited warranty
