L-force Loader
System requirements
Connection with the target system
8 DMS 4.0 EN - 07/2007
L
2.2 Connection with the target system
The communication with the target system (controller, Drive PLC, etc.) requires a fieldbus-
specific interface module for the PC and the corresponding fieldbus modules for the target
systems to be connected.
r For system bus (CAN) communication, Lenze offers the following interface modules for
the PC:
L-force 9400 Servo Drives
If devices of the "L-force 9400 Servo Drives" series are used, communication can also take
place via the diagnostic interface X6 on the controller. For this purpose Lenze offers the
following interface module for the PC:
Communication accessories PC port
PC system bus adapter 2173
incl. connection cable and voltage supply adapter
• for DIN keyboard connection (EMF2173IB)
• for PS/2 keyboard connection (EMF2173IBV002)
• for PS/2 keyboard connection with electrical isolation (EMF2173IBV003)
Parallel port
(LPT port)
PC system bus adapter 2177
incl. connection cable (EMF2177IB)
USB
(Universal Serial Bus)
Note!
• Detailed information on the PC system bus adapter can be found in the "CAN
Communication Manual".
• Please read the documentation delivered together with the PC system bus
adapter!
Communication accessories PC port
PC diagnostic adapter E94AZCUS
incl. connection cables
USB
(Universal Serial Bus)
