L-force Loader
User interface
Toolbar
4.3 Toolbar
Via the icons of the toolbar you can directly execute some of the most frequently used
menu commands without making a detour via the Menu bar .
r Simply click an icon to activate the corresponding command.
O
Tip!
If you position the mouse pointer for a short time over an icon, a "tool tip" will be
displayed with information about the corresponding function.
4.4 Function area
The function area shows all presently available functions in form of icons. The functions
can be activated by a mouse click.
4.5 Dialog area
The dialog area displays input dialogs, buttons and text fields with additional information
about the active function.
4.6 Status bar
The status bar indicates the communication status (online/offline) and the device address.
r For Lenze PLCs, the PLC program status is indicated as well.
r For L-force 9400 Servo Drives, the application status is indicated as well.
Icon Function
Starts the PLC program/application
Stops the PLC program/application
Displays help topics
