L-force Loader
User interface
Menu bar
4.2 Menu bar
The menu bar is used to access the menu commands for the »L-force Loader«.
r A click on an item of the main menu opens the corresponding menu and lists the menu
items contained in it.
r Click a menu item to execute the corresponding function.
– Menu items which are displayed in light grey are currently deactivated because the
execution of the corresponding function would not make any sense in the current
program state.
"Options" menu
The Options menu provides commands for the configuration of the »L-force Loader«:
Command Function
System bus configurator... Starts the Lenze system bus configurator
• Use the system bus configurator to easily configure the communication
parameters of the Lenze PC system bus adapters connected to your PC.
• For safety reasons, all »L-force Loader« functions/menu commands are
deactivated while the system bus configurator is running.
• For detailed information on the system bus configurator, please refer to the
Online Help for the system bus configurator.
Diagnostics configurator... Starts the Lenze diagnostics configurator
• Use the diagnostics configurator to easily configure the communication
parameters of the Lenze PC diagnostic adapters connected to your PC.
• For safety reasons, all »L-force Loader« functions/menu commands are
deactivated while the diagnostics configurator is running.
LECOM configurator... Starts the Lenze LECOM configurator
• For safety reasons, all »L-force Loader« functions/menu commands are
deactivated while the LECOM configurator is running.
• For detailed information on the LECOM configurator, please refer to the
DriveServer documentation.
DriveServer configurator... Starts the Lenze DriveServer configurator
• For safety reasons, all »L-force Loader« functions/menu commands are
deactivated while the DriveServer configurator is running.
• For detailed information on the DriveServer configurator, please refer to the
DriveServer documentation.
IP address... Specifies the IP address
• Only required for the "L-force 9400 Servo Drives" series if communication with
the controller is to take place via Ethernet NRT.
Activation of safety scan A safety scan is made before every action.
• If this option is activated, a tick appears next to the menu command.
Activation of all notes Repeated note display can be stopped by activating the Do not display this note
again checkbox in the note dialog box.
Use the command Activation of all notes to reset all settings made, i.e. all notes will
be displayed again.
Language Selection of the language for the user interface.
