Page 49: Fault messages
EDS94AYFLF EN 3.2 - 10/2010
L
49
Digital frequency extension module | Parameter setting & configuration
Fault messages
DFIN (MXI1): Track error A-/A [0x00990000]
DFIN (MXI1): Track error B-/B [0x00990001]
DFIN (MXI1): Track error Z-/Z [0x00990002]
DFIN (MXI1): Signal error enable/lamp control [0x00990003]
DFIN (MXI1): Supply cannot be corrected anymore [0x00990004]
DFOUT (MXI1): Maximum frequency reached [0x00990005]
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of signal cable for track A.
• Check signal cable for track A.
• Check encoder.
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of signal cable for track B.
• Check signal cable for track B.
• Check encoder.
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of signal cable for track Z.
• Check signal cable for track Z.
• Check encoder.
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of signal cable for "Enable"
signal or no "Enable" signal available.
• Check signal cable for "Enable" signal.
• Check encoder.
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1: The
encoder voltage controlled by the digital frequency input
has reached the voltage limit.
Check encoder.
Response (Lenze setting in bold)
Setting:
(; Adjustable response)
;
No System fault ; Fault ; Trouble ; Quick stop by trouble ; Warning locked : Warning ; Information
Cause
Remedy
Digital frequency extension module in MXI1: Limit
frequency at the digital frequency output reached.
• The digital frequency has reached the limit value set
Check set limit value.
