2 System and product description
2.4 Available bus coupler modules
10
Lenze · I/O system 1000 · commissioning guidelines for the PLC Designer · DMS 1.2 EN · 11/2012 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.4 Available bus coupler modules
2.5 Available I/O compound modules
Type designation Short designation Description Process data
EPM-S110 CANopen CANopen bus coupler module -
EPM-S120 PROFIBUS PROFIBUS bus coupler module -
EPM-S130 EtherCAT EtherCAT bus coupler module -
EPM-S140 PROFINET PROFINET bus coupler module -
EPM-S150 DeviceNet DeviceNet bus coupler module -
EPM-S160 Modbus TCP Modbus TCP bus coupler module -
Type designation Short designation Description Process data
Digital-I/O
EPM-S200
DI2, DC 24V 2 digital inputs 2 bits
EPM-S201 DI4, DC 24V 4 digital inputs 4 bits
EPM-S202 DI8, DC 24V 8 digital inputs 8 bits
EPM-S203 DI4, DC 24V 4 digital inputs
• Three-wire conductor connection
4 bits
EPM-S204 DI2, NPN, DC 24V 2 digital inputs, npn 2 bits
EPM-S205 DI4, NPN, DC 24V 4 digital inputs, npn 4 bits
EPM-S206 DI8, NPN, DC 24V 8 digital inputs, npn 8 bits
EPM-S207 DI2 time stamp, DC 24V 2 digital inputs ENP 8 bytes, writing
EPM-S300 DO2, DC 24V, 0.5A 2 digital outputs, 0.5 A 2 bits
EPM-S301 DO4, DC 24V, 0.5A 4 digital outputs, 0.5 A 4 bits
EPM-S302 DO8, DC 24V, 0.5A 8 digital outputs, 0.5 A 8 bits
EPM-S303 DO2, NPN, DC 24V, 0.5A 2 digital outputs, npn 2 bits
EPM-S304 DO4, NPN, DC 24V, 0.5A 4 digital outputs, npn 4 bits
EPM-S305 DO8, NPN, DC 24V, 0.5A 8 digital outputs, npn 8 bits
EPM-S306 DO2, DC 24V, 2A 2 digital outputs, 2 A 2 bits
EPM-S308 DO2, relay 230V, 3A 2 relay outputs 2 bits
EPM-S309 DO4, DC 24V, 2A 4 digital outputs, 2 A 4 bits
EPM-S310 DO2 time stamp, DC 24V 2 digital outputs, 0.5 A, ENP 8 bytes, reading
2 bytes, writing
Analog I/O
EPM-S400
AI2, 12BIT, DC 0…10V 2 analog inputs, 0 … 10 V DC 4 bytes
EPM-S401 AI4, 12BIT, DC 0…10V 4 analog inputs, 0 … 10 V DC 8 bytes
EPM-S402 AI2, 12BIT, DC 0/4…20mA 2 analog inputs, 0/4 … 20 mA 4 bytes
EPM-S403 AI4, 12BIT, DC 0/4…20mA 4 analog inputs, 0/4 … 20 mA 8 bytes
EPM-S406 AI2, 16BIT, DC +/-10V 2 analog inputs
for voltage measurement ±10 V
4 bytes
EPM-S408 AI2, 16BIT, DC 0/4…20mA 2 analog inputs
for current measurement
4 bytes
EPM-S500 AO2, 12BIT, DC 0…10V 2 analog outputs, 0 … 10 V DC 4 bytes
EPM-S501 AO4, 12BIT, DC 0…10V 4 analog outputs, 0 … 10 V DC 8 bytes
