Cam Designer Professional
System requirements
Connection with the target system
8 3.0 EN - 08/2005
L
2 System requirements
The following minimum requirements on hardware and software must be met to use the
»Cam Designer Professional«.
 Microsoft® Windows ME®, Microsoft® Windows NT® 4.0 (as of Service Pack 5), Win-
dows® 2000 (as of Service Pack 2) or Windows XP
 64 MByte RAM
128 MByte RAM (XP, 2000)
 IBM compatible PC (CPU: Pentium 90 MHz processor or faster)
 Super VGA screen
 Hard disk with at least 120 MB of free disk space
 CD-ROM drive
 Mouse (Microsoft-compatible)
2.1 Connection with the target system
The communication with the target system (controller, Drive PLC, etc.) requires a fieldbus-
specific interface module for the PC and the corresponding fieldbus modules for the target
systems to be connected.
For system bus (CAN) communication, Lenze offers the following components as interface
module for the PC:
Bus system Max. number of target systems
PC port Required hardware components
System bus (CANopen) 63
Parallel
port
(LPT port)
PC system bus adapter 2173
incl. connecting cable and voltage supply adapter
• for DIN keyboard connection
(EMF2173IB)
• for PS/2 keyboard connection
(EMF2173IBV002)
• for PS/2 keyboard connection with electrical isolation
(EMF2173IBV003)
USB
(Universal Serial Bus)
PC system bus adapter 2177
incl. connection cable
(EMF2177IB)
