Cam Designer Professional

Operation

Online Download

3.0 EN - 08/2005

6.12

Online Download



How to make an online download:

1. Switch the »Cam Designer Professional« online by clicking FileConnection to OPC

server or

• The button online/offline is only active if the LDS-DriveServer has been started.

The icon

for the LDS-DriveServer is situated in the status bar.

• If the red point in the icon becomes green, the system is online.

2. Select EditProject settings to open the Settings dialog box.
3. Select in Controller data the drive to which the data is to be downloaded.

4. Select FileCreate and download LCx-file or

to activate the profile or cam

download.
• The data for the current slave axis are written into the *.lcx-file.
• After the download has been started with the button, a progress dialog appears.



Tip!
For the commissioning of production machines, the *.lc9-file can be attached to the

PLC program.



Note!

The download time increases if
• a high bus load (cross communication) exists.
• many data was changed.
