Scope of supply
Pos.
Description
0
9350 braking unit
Accessory kit with shield sheets and fixing material
Operating Instructions
Elements of the braking unit
Pos.
Description
1
Terminals
+UG, −UG
DC−bus voltage
T1, T2
Temperature switches (only 9351 brake module)
RB1, RB2
Brake resistor (only 9352 brake chopper)
2
LED
Green
Voltage is applied to terminals +UG, −UG
Yellow
Braking unit is in braking operation
3
Switches
S1, S2
Setting the switching thresholds of the braking unit
S3
Setting of the configuration as master or slave for parallel operation
4
Synchronisation
interface
E1, E2
Inputs
A1, A2
Outputs
