ASSEMBLY INSTRUCTIONS
Electronic Acre Meter
Figure 2-27: Electronic Acre Meter
Acre Meter Bracket
Pick Up Switch
Bracket
5K332
Machine Screw,
#10-24 X 3/4”
Lock Washer, #10
Nut, #10-24
Machine Screw,
#8-32 X 1 1/4”
Flat Washer, #8
Lockwasher, #8
Nut, #8-32
Pick Up Switch
Adhesive
Mount Base
Magnet w/Wheel
Screw, 3/8-16 X 1”
Lockwasher, 3/8
Nut,3/8-16
Clutch Support Bracket 5K209
