2-6 1P126
ASSEMBLY INSTRUCTIONS
Step 9
Position Roller Assembly between frame members and
attach flange bearing to frame with grease fittings toward
front. See Figure 2-7.
NOTE
Deflectors and transport wheels are not shown in steps
6, 7 and 8 for purposes of clarity.
Figure 2-7: Seeder Assembly Step 9
NOTE
Front
Screw,1/2 X 2” (Pick Up Frames)
Screw,1/2 X 1-3/4” (Drawbar Frames)
Lockwasher,1/2
Hex Nut,1/2
• Tighten Bearing
Collars in the
Direction of Rotation.
