3-10 1P126
OPERATION
Transmission Clutch
The clutch is controlled by a toggle switch mounted to the
tractor by a hook and loop type fastener. Clutch
characteristics are as follow:
1. The clutch is disengaged when power (12 volts) is
applied. If there is a power failure or electrical
problem, the seeder will continue to operate, so the
machine must be raised to stop seeding.
2. Seed shafts will not rotate when the machine is
backed up.
3. The switch box contains a standard 5 amp fuse.
4. The clutch must be disengaged (power applied)
when seed shafts are turned manually for calibration.
Charging the Hydraulic System
Ensure that the hydraulic system is full of oil. If a
hydraulic component is removed, repaired, or replaced
the system, must be purged of air before operations. To
purge the system or air, unpin the rod end of both
cylinders. Align or prop the cylinders into position so that
the rod will not interfere with anything during its travel.
Slowly engage the tractor hydraulics fully extending and
retracting both cylinders. Repeat several times until the
action of both cylinders is positive and immediately
responsive. Do not loosen or crack any fittings.
Reconnect the rod end of both cylinders.
SSP308 SS308 764 18 8
SSP310 SS310 764 18 10
SSP312 SS312 764 18 12
GLP643 SSLP643 917 21 5
SLP8 SL8 4147 95 8
SLP10 SL10 4147 95 10
SLP12 SL12 4147 95 12
SLP204 SLP2041 1690 39 4
SLP206 SLP611 1690 39 6
SLP304 845 19 4
SLP306 845 19 6
LSP5 1690 39 5
LSP6 1690 39 6
LSS6 1690 39 6
SLP208 SLP2081 SL208 SL2081 1528 35 8
SLP210 SLP2101 SL210 SL2101 1528 35 10
SLP212 SLP2121 SL212 SL2121 1528 35 12
SLP308 SLP3081 SL308 SL3081 1528 35 8
SLP310 SLP3101 SL310 SL3101 1528 35 10
SLP312 SLP3121 SL312 SL3121 1528 35 12
BOS4F BOS4F1 BOSB4F2 600 14 4
BOS6F BOS6F1 BOSB6F2 600 14 6
Table 3-4: Pulse Table
MODEL
Pulses
Per Acre
Pulses
per 1000
sq.’ Width
