Specifications, Specifications -3 – Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 5/14 User Manual
Page 9
TM
Model 3600
M0249-01
Rev. 5/14
1-3
Specifications
SPECIFICATIONS
Specification
Conventional Hoppers
Number of Rows
16R N 70 CM Y
Weight Empty (Mechanical)
7,246 kg
Weight Empty (EdgeVac)
7,353 kg
Transport Height
3.5M
Planting Length
7.4M
Transport Length
13.3M
Planting Width
11.6M
Transport Width
3.5M
Seed Capacity
1.75 bu. (EdgeVac/Hopper); 1.90 bu. (Mechanical/Hopper)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
TRACTOR HYDRAULIC REQUIREMENTS
Configuration
No Optional Pumps
Tractor Mounted PTO Pump
Mechanical Meter
1,2
2 SCV
57 L/min
EdgeVac Meter
1,2
3 SCV
113 L/min
2 SCV
57 L/min
2
Wing down pressure option adds 1 SCV to conventional only.
The Model 3600 Twin-Line Planter is available with EdgeVac or mechanical meters, conventional hoppers or Air Seed
Delivery system (ASD), Interplant, and various other options. Liquid or dry fertilizer application equipment and various
row unit attachments are also available.
Information used in these instructions was current at time of printing. However, due to Kinze’s ongoing product
improvement, production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing,
Inc. reserves the right to change specifications or design without notice and without incurring obligation to install the
same on machines previously manufactured.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing direction machine
travels in use unless otherwise stated.
GENERAL INFORMATION
TOOLS REQUIRED
Hardware Size / Tool Required
1/4
" = 7/16"
7/16
" = 5/8"
(nut for 7/16" hardware uses 11/16" tool)
3/4
" = 11/8"
11/4" = 17/8"
5/16
" = 1/2"
1/2
" = 3/4"
7/8
" = 15/16"
11/2" = 21/4"
3/8
" = 9/16"
5/8
" = 15/16"
1" = 11/2"
