Model 3600 M0249-01
12/12 6-5
Lubrication and Maintenance
Lubricate all U-joint slides daily with a high quality lubricant.
Center post is clad with stainless steel. Keep stainless steel
surface clean and free of any lubrication to prolong service life.
See “Wear Pad Adjustment/Replacement” for more information.
CENTER POST
U-JOINT SLIDES
Center post
U-joint slide
NOTICE
Any oil or grease on center post and poly wear pads will attract dirt
and accelerate wear. Do not lubricate center post and poly wear pads.
