Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 5/14 - Manual (Page 19)

TM
Model 3600 M0249-01
Rev. 5/14 2-7
Machine Operation
CYLINDER INFORMATION
Wing Down Pressure
Cylinder
Row Marker Cylinder Rotation Cylinder Tongue Cylinder Wing Lift Cylinder
Intended Use
Double acting
applications
Double acting
applications
Double acting
applications
Double acting
applications
Double acting
applications
Piston Ductile iron Ductile iron Ductile iron Ductile iron Ductile iron
Gland Ductile iron Ductile iron Ductile iron Ductile iron Ductile iron
Tube ST 52 Dom ST 52 Dom ST 52 Dom ST 52 Dom ST 52 Dom
Rod 1045 Nitro rod 1045 Nitro rod 1045 Nitro rod 1045 Nitro rod 1045 Nitro rod
End Mounts U-bracket Sleeve Tang None Gimble
Tube Seal
O-ring with polytemp
back-up
Buna O-Ring with
polytemp back-up Buna O-Ring with
polytemp back-up O-ring with polytemp
back-up
Buna O-Ring with
polytemp back-up
Rod Seal Polyester alloy u-cup Polyester alloy u-cup Polyester alloy u-cup Polyester alloy u-cup Polyester alloy u-cup
Rod Wiper
Polyester alloy snap
in
Polyester alloy snap
in
Polyester alloy snap
in
Polyester alloy snap
in
Polyester alloy snap
in
Piston Seal T-seal hnbr T-seal hnbr PTFE T-seal hnbr PTFE
Specifications
Product
Category
Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder Hydraulic Cylinder
Maximum
Stroke
8" (20.32 cm) 20.62" (52.3748 cm) 16" (40.64 cm) 73" (185.42 cm) 6" (15.24 cm)
Working
Pressure
3000 PSI
(20684.27 kPa)
3000 PSI
(20684.27 kPa)
3000 PSI
(20684.27 kPa)
3000 PSI
(20684.27 kPa)
3000 PSI
(20684.27 kPa)
Bore Size 3" (7.62 cm) 2" (5.08 cm) 4" (10.16 cm) 3" (7.62 cm) 4" (10.16 cm)
Shaft
Diameter
1.25" (31.75 mm) 1.25" (31.75 mm) 1.50" (38.1 mm) 1.75" (44.45 mm) 1.50" (38.1 mm)
Cylinder
Configuration
Simple Simple Simple Simple Simple
Cylinder
Action
Double Double Double Double Double
Material Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron Steel, Ductile Iron
Mounting
Method
U-Bracket Sleeve Tang None Gimble
Mount
Location
End Cap End Cap End Cap End Cap Side's of Barrel
Cylinder
Style
Welded Welded Welded Welded Welded
