Kinze 3600 Lift and Rotate Planter (70 CM) Rev. 5/14 - Manual (Page 22)

M0249-01 Model 3600
2-10 Rev. 5/14
TM
Machine Operation
HYDRAULIC HOSE INFORMATION (Continued)
Part Number A1116 A12042 A1404 A1444 A18300 A3122
Description
Hose Assembly
¼ " X 136"
(06F - 06F)
Hose Assembly
⅜ " X 228"
(08F - 08F)
Hose Assembly,
½" X 41"
(10F - 10F)
Hose Assembly,
½" X 250"
W/Tip (½M
NPTF - 10F)
Hose Assembly,
⅜ " X 250"
W/Tip
(½M NPTF - 08F)
Hose Assembly,
⅜ " X 10½"
(08F - 08F)
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly Hose; Assembly
I.D. ¼ " (6.35 mm) ⅜ " (9.525 mm) ½" (12.7 mm) ½" (12.7 mm) ⅜ " (9.525 mm) ⅜ " (9.525 mm)
O.D. 0.53" (13.462 mm) .63" (16.002 mm) 0.8" (20.32 mm) 0.8" (20.32 mm) .63" (16.002 mm) .63" (16.002 mm)
Minimum Bend
Radius
4" (10.16 cm) 2" (5.08 cm) 2.8" (7.112 mm) 2.8" (7.112 mm) 2" (5.08 cm) 2" (5.08 cm)
Working
Pressure
3275 psi
(22580.33 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Single Wire
Braid
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
Part Number A3139 A8267 A1055
Description
Hose Assembly,
⅜ " X 254"
(08F - 08F)
Hose Assembly,
½" X 58"
(10F - 10F)
Hose Assembly,
⅜ " x 66"
Product
Category
Hydraulic Hose Hydraulic Hose Hydraulic Hose
Product Form Hose; Assembly Hose; Assembly Hose; Assembly
I.D. ⅜ " (9.525 mm) ½" (12.7 mm) ⅜ " (9.525 mm)
O.D. .63" (16.002 mm) 0.8" (20.32 mm) .63" (16.002 mm)
Minimum Bend
Radius
2" (5.08 cm) 2.8" (7.112 mm) 2" (5.08 cm)
Working
Pressure
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
3250 PSI
(22407.96 kPa)
Temperature
Range
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
-40°F - +212°F
(-40°C - +100°C)
Material
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Modified Nitrile
Type C2
Specialized
Construction
Single Wire
Braid
Single Wire
Braid
High tensile
steel wire
Media Hydraulic Fluid Hydraulic Fluid Hydraulic Fluid
Application
Agricultural;
Construction
Agricultural;
Construction
Agricultural;
Construction
