Specifications
Specification
Conventional Hoppers
Number of Rows
12R N 30 Y/T
12R W 36-38 Y
16R N 30 Y/T
16 R 7.5" Y
Weight Empty (Mechanical)
12,780 lb (5,796.91 kg) 13,522 lb (6,133.47 kg) 15,730 lb (7,135.00 kg) 19,750 lb (8,958.45 kg)
Weight Empty (EdgeVac)
13,185 lb (5,980.62 kg)
---
16,210 lb (7,352.73 kg) 20,230 lb (9,176.17 kg)
Transport Height
11' 4" (3.5M)
11' 4" (3.5M)
11' 5" (3.5M)
11' 5" (3.5M)
Planting Length
21' 0" (6.4M)
22'0" (6.7M)
24' 0" (7.4M)
24' 0" (7.4M)
Transport Length
36' 10" (11.3M)
45'10" (14M)
46' 10" (14.3M)
46' 10" (14.3M)
Planting Width
31' 2" (9.5M)
37'2" (11.4M)
41' 2" (12.6M)
41' 2" (12.6M)
Transport Width
11' 2" (3.5M)
13'4" (4.1M)
11' 2" (3.5M)
11' 2" (3.5M)
Seed Capacity
1.75 bu. (EdgeVac/Hopper); 1.90 bu. (Mechanical/Hopper)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
Specification
Air Seed Delivery (ASD)
Number of Rows
12R N 30 Y
16R N 30 Y
16 R 7.5" Y
Weight Empty (Mechanical)
12,660 lb (5,742.48 kg)
15,120 lb (6,858.32 kg)
21,140 lb (9,588.94 kg)
Weight Empty (EdgeVac)
13,065 lb (5,926.18 kg)
15,600 lb (7,076.04 kg)
19,620 lb (8,899.48 kg)
Transport Height
12' 6" (3.9M)
12' 6" (3.9M)
12' 6" (3.9M)
Planting Length
21' 0" (6.4M)
24' 0" (7.4M)
24' 0" (7.4M)
Transport Length
36' 10" (11.3M)
46' 10" (14.3M)
46' 10" (14.3M)
Panting Width
31' 2" (9.5M)
41' 2" (12.6M)
41' 2" (12.6M)
Transport Width
11' 2" (3.5M)
11' 2" (3.5M)
11' 2" (3.5M)
Seed Capacity
80 bu.
ASD Fill Height (planting position)
8' 2" (2.5M)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Wing/Lift Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
TRACTOR HYDRAULIC REqUIREMENTS
Configuration
No Optional Pumps
Tractor Mounted PTO Pump
Mechanical Meter
1,2
2 SCV
15 gpm min.
EdgeVac Meter
1,2
3 SCV
30 gpm min.
2 SCV
15 gpm min.
ASD (with Mechanical Meter)
3
3 SCV
25 gpm min.
2 SCV
15 gpm min.
ASD (with EdgeVac)
2
4 SCV
40 gpm min.
3 SCV
25 gpm min.
1
Hydraulic drive adds 1 SCV + 5 gpm (mechanical) or 10 gpm (EdgeVac) min. to requirements.
2
Wing down pressure option adds 1 SCV to conventional only.
3
Hydraulic drive not available for ASD/EdgeVac configuration.
