Model 3600 M0236-01
Rev. 7/14 6-11
Lubrication and Maintenance
SPECIAL TORqUE VALUES
Row unit parallel linkage bushing
hardware
130 ft-lb (176 Nm)
5/8 " No till coulter spindle hardware 120 ft-lb (162 Nm)
Center section transport tire lug nuts 180 ft-lb
Wing ground drive tire lug bolts
90 ft-lb
TORqUE VALUES- Pneumatic Down Pressure
Diameter Torque Value
⅛ " NPT 120 in-lb Maximum
½ "-13 180 in-lb Maximum
¾ "-16 180 in-lb Maximum
NOTE: Use these torque values with pneumatic
down pressure components.
Cylinder Rod Piston Retaining Nut Torque Chart
Non-Nylock Nut Nylock Nut
½"-20
55-70 ft-lb
(75-95 N-m)
45-55 ft-lb
(61-75 N-m)
¾"-16
115-125 ft-lb
(156-169 N-m)
100-115 ft-lb
(136-156 N-m)
⅞ "-14
150-180 ft-lb
(203-244 N-m)
130-150 ft-lb
(176-203 N-m)
1"-14
275-330 ft-lb
(373-447 N-m)
250-275 ft-lb
(339-373 ft-lb)
1⅛"-12
300-375 ft-lb
(407-508 N-m)
275-300 ft-lb
(373-407 N-m)
1¼"-12
300-375 ft-lb
(407-508 N-m)
275-300 ft-lb
(373-407 N-m)
