27 rate charts – Kinze 3600 Lift and Rotate Planter Rev. 7/14 User Manual
Page 105
TM
Model 3600
M0236-01
Rev. 7/12
5-27
Rate Charts
LIqUID fERTILIzER SqUEEzE PUMP APPLICATION RATES (EdgeVac)
28 TOOTH CONTACT WHEEL DRIVE SPROCKET
GALLONS PER ACRE
Drive
Driven
30" Rows
36" Rows
38" Rows
Drive
Driven
30" Rows
36" Rows
38" Rows
15
62
5.7
4.7
4.5
17
15
26.7
22.2
21.1
15
46
7.7
6.4
6.1
23
19
28.5
23.7
22.5
19
46
9.7
8.1
7.7
30
23
30.7
25.6
24.2
15
30
11.8
9.8
9.3
24
17
33.2
27.7
26.2
17
30
13.3
11.1
10.5
46
30
36.1
30.1
28.5
15
23
15.4
12.8
12.1
50
30
39.2
32.7
31.0
46
62
17.5
14.6
13.8
30
17
41.5
34.6
32.8
19
23
19.4
16.2
15.4
46
24
45.1
37.6
35.6
46
50
21.7
18.0
17.1
30
15
47.1
39.2
37.2
24
23
24.6
20.5
19.4
62
30
48.7
40.5
38.4
NOTE: 22, 28 and 44 tooth drive sprockets are NOT applicable to all rate charts. Check title to ensure proper rate chart is
selected. DO NOT USE 44 tooth drive sprockets (60 cell soybean discs) with Liquid fertilizer Squeeze Pump Package.
Chart is for planters equipped with contact drive and calculated based on a solution weighing ten pounds per gallon.Check
tires for correct operating pressure.
NOTE: fertilizer application rates can vary from the above chart. To prevent application miscalculations, make field checks
to be sure you are applying fertilizer at the desired rate.
NOTE: Optional two-speed point row clutch is located ahead of liquid fertilizer squeeze pump Activating two-speed point
row clutch reduced rate switch will cause same percent of reduction in liquid fertilizer (squeeze pump) application rates.
LIqUID fERTILIzER SqUEEzE PUMP APPLICATION RATES (EdgeVac)
22 TOOTH CONTACT WHEEL DRIVE SPROCKET
GALLONS PER ACRE
Drive Driven 30" Rows
36" Rows
38" Rows
Drive Driven 30" Rows
36" Rows
38" Rows
19
62
5.7
4.7
4.5
24
17
26.1
21.8
20.6
19
46
7.6
6.4
6.0
46
30
28.4
23.6
22.4
24
46
9.7
8.0
7.6
50
30
20.8
25.7
24.3
19
30
11.7
9.8
9.2
30
17
32.6
27.2
25.8
17
23
13.7
11.4
10.8
46
24
35.5
29.5
28.0
19
23
15.3
12.7
12.1
30
15
37.0
30.8
29.2
23
24
17.7
14.8
14.0
62
30
38.2
31.9
30.2
50
46
20.1
16.8
15.9
50
23
40.2
33.5
31.7
23
19
22.4
18.7
17.7
46
19
44.8
37.3
35.4
30
23
24.1
20.1
19.0
62
24
47.8
39.8
37.7
To check the exact number of gallons your fertilizer attachment will actually deliver on a 30" row spacing:
1. Remove hose from one fertilizer opener and insert it into a collection container secured planter frame.
2. Engage fertilizer attachment and drive forward for 174'.
3. Measure fluid ounces caught in container and multiply by 100. Divide that amount by 128. Result is gallons of
fertilizer delivered per acre when planting in 30" rows. To convert this delivery rate for wider rows, multiply by the
following conversion factors:
36" multiply by 0.83
38" multiply by 0.79
4. Rinse collection container and repeat test on other rows if necessary.
