9 DIN-approved probes 39 2014-06-12
9.3 Probes for operation in air, water and oil
A Sensor short circuit can only be detected with a double thermocouple.
Note: Because of the high response accuracy, the use of thermowells (pockets) is not admissible.
Actual type designation Old type
designation Probe type Temperature range Install. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
90.2006/10-390-1003-1-8-250-104/000 90.210-F95 1 x Pt100 max. 300°C 250
Thermocouples Data Sheet 90.1006
901006/45-551-2043-2-xxxx-11-xxxx 2 x NiCr-Ni, Typ E „K“ max. 1 50°C 50...2000
