3 Mounting and removal 9 2014-06-12
3.1 Mounting location
3.2 Close mounting
3.3 Electrical isolation
a Preferably vibration-free, so that screw terminals cannot work loose!
a Free from aggressive media, such as strong acids and caustic solutions and preferably free from dust and powder or
other suspended matter, so that ventilation slots cannot get blocked up!
a Maintain at least 10 cm of space at the top,
so that the release slot can be accessed with a screwdriver from above.
a Several instruments can be mounted right next to one another, without a gap.
(1) Measurement input (2) Relay output
(3) Binary input (4) Binary output
(5) Setup interface (6) LC Display
(7) Supply
