7 Configuration level 23 2014-06-12
7.2 C112 Setting for a double thermocouple
7.3 C113 Unit, decimal place
7.4 C114 Device function
Double thermocouple Comment
0 no sensor short circuit not detected!
1 yes only available for C111 from 037 to 048
v Chapter 7.1 “C111 Analog inputs”
Can detect a sensor short circuit
Unit, decimal place Comment
0 °C, no decimal place
1 °C, one decimal place
2 °F, no decimal place
3 °F, one decimal place
Device function Comment
0 Initial commissioning of TB
temperature limiter Whatever the switching state of the relay before the power failure, the TB
remains locked when the power returns.
1 Temperature limiter TB Release is only necessary if the temperature is exceeded
2 Temperature monitor TW Automatic release
A
When the unit changes to °F, the measurement is
converted. All other measurement-related values,
such as AL, are unchanged!
