8 Technical data 2014-06-12 30
8 Technical data
8.1 Analog inputs
Resistance thermometers
Thermocouples
Designation Measuring range Accuracy 1
Pt 100 EN 60751 -200 to +850°C 0.1%
KTY11-6 PTC -50 to +150 °C 1%
Pt 1000 EN 60751 -200 to +850°C 0.1%
Connection circuit 2-wire, 3-wire circuits
Sampling 210 ms
Input filter 2nd order digital filter; filter constant adjustable from 0 to 100secs
Features 2 x Pt100 for differential measurement, display can also be programmed in °F
Designation Measuring range Accuracy 1
Fe-CuNi L DIN 43710 -200 to +900°C 0.4%
Fe-CuNi J EN 60584 -200 to +1200°C 0.4%
Cu-CuNi U DIN 43710 -200 to +600°C 0.4%
Cu-CuNi T EN 60584 -200 to +400°C 0.4%
NiCr-Ni K EN 60584 -200 to +1372°C 0.4%
