7 Configuration level

2014-06-12

7.1

C111 Analog inputs

Analog input

Comment

Setting range for AL:
(can be restricted via
setup)

Limits for
overrange/
underrange

001

Pt 100
EN 60751

in 3-wire circuit

-1999 to +9999°C

-205°C/ +855°C

006

Pt 1000
EN 60751

in 3-wire circuit

-1999 to +9999°C

-205°C/ +855°C

601

KTY11-6 PTC

sensor in 2-wire circuit

-1999 to +9999°C

-55°C/ +155°C

003

Pt 100
EN 60751

in 2-wire circuit

-1999 to +9999°C

-205°C/ +855°C

005

Pt 1000
EN 60751

in 2-wire circuit

-1999 to +9999°C

-205°C/ +855°C

024

2x Pt 100 DIN

for differential measurement

-1999 to +9999°C

-205°C/ +855°C

The TB/TW can measure the differential of two Pt 100 resistance thermometers in a 2-wire
circuit.
Measurement input INP (terminal 1 and 2) acquires the first temperature.
The second measurement input IN2 (terminal 2 and 3) acquires the second temperature.
The differential DIF = INP - IN2 is displayed and evaluated.

Setting range for ALD: -1999 to 9999

Factory setting
