8 Technical data

2014-06-12

8.3

Binary input

8.4

Binary outputs

8.5

Supply

8.6

Test voltages to EN 60730, Part 1

Connection

Function

1 floating contact

Configurable unlocking, keyboard inhibit, level inhibit

1 relay

10,0000 operations at a contact rating of 3A/230V, 50Hz resistive load
Contact protection circuit:
safety fuse 3.15AT, installed in the pole contact arm within the instrument

1 Binary output

24 V DC / 20mA logic signal, short-circuit proof

Supply

20 to 30V AC/DC, 48 to 63Hz

110 to 240 V AC +10/-15%, 48 to 63Hz

Power consumption

5 VA

Between input or output and supply

- at 110 to 240 V AC supply +10% /-15%

3.7kV/50Hz

- at 20 to 30V AC/DC supply, 48 to 63 Hz

3.7kV/50Hz
